" SQU " 8910-DPA-23-V-02 SQUARE-D COMPANY
DEFINITE PURPOSE CONTACTOR - SQU8910DPA23V02>
Description
DEFINITE PURPOSE CONTACTOR
- Compact Design
- Industry Standard
- Mounting
- Double Break Contacts
- Low Coil VA
- Straight-Through Wiring
- Quick Connect Terminals and Binder Head Screws for Wiring Ease
- DPA Contactors Rated 200,000 Operations
- Approvals: UL Listed File Number E42240 CCN NLDX; CSA Certified File Number LR25490 Class 321104; CE Marked
- Enclosure Type: Open
- Maximum Voltage Rating: 600 VAC
- Mounting Type: Panel
- Phase: 1-Phase
- Type: DP
| Coil Voltage | 120 VAC |
| Contact Current Rating | 25 A |
| Contact Voltage Rating | 600 VAC |
| Depth | 82.5 mm |
| Dimensions | 60.2 x 76 x 82.5 mm |
| Horse Rating Power | 10 HP @ 230 V ac (3 Phase), 15 HP @ 460 V ac (3 Phase), 2 HP @ 115 V ac (1 Phase), 20 HP @ 575 V ac (3 Phase), 5 HP @ 230 V ac (1 Phase) |
| Length | 60.2 mm |
| Maximum Operating Temperature | 65 °C |
| Minimum Operating Temperature | 0 °C |
| Mounting Type | Panel |
| Normal State Configuration | 3NO |
| Number of Poles | 3 |
| Operating Temperature Range | 0 to +65 °C |
| Pole and Throw Configuration | 3PST |
| Relay Type | Electromechanical |
| Series | 8910DP |
| Standards Met | CE Recognized, CSA Certified, UL Listed |
| Terminal Type | Quick Connect |
| Width | 76 mm |
