22-TOOTH MPB #32-CHAIN SPROCKETS
22 mm Bore
ISO No. 06B-1 Steel Hub Sprocket
For Ametric® No. 32 Chain with
9.525mm Pitch
5.72mm Roller Width
6.35mm Roller Dia.
5.25mm (B1)
71 mm (de)
50 mm Hub Dia. (dn)
28 mm (A)
022 Teeth
Steel 22 mm H8 bore , 6x2.8 keyway M6 screw hole over keyway and at 90°
NI 05242017 EH
