115-V ELECTRIC OIL TRANSFER PUMPS
Graco's APEX transfer pumps are designed specifically to transfer bulk oils and hydraulic fluids anywhere.
Self-priming, positive displacement design
Pumps petroleum and synthetic based lubricants up to 8 gpm (30 lpm)
Built-in bypass valve
Includes suction tube, fluid hose, dispense valve and bung adapter
Output flow: 4.25 gpm
65 psi
Weight: 25 lbs
Voltage/Current: 115 VAC, 60 Hz, 9.2 amps
Power cord: 30"
Hose size: 8 ft, 3/4" ID
Suction tube: 34"
Inlet Port: 1" NPT female
Outlet Port: 3/4" NPT female
Includes: 3/4" x 8' hose, 1" x 34" suction tube, and 3/4" outlet dispenser valve
Wetted Parts: Carbon steel with zinc plating, stainless steel, galvanized steel, aluminum, nitrile, rubber, PVC, PVC cement
Materials: Antifreeze, Motor oil, Gear oil, Used oil, Hydraulic fluid, Cutting oil, Oil
Applications: Chemical transfer, Oil transfer, Pumping, Fluid transfer
Industries: Mining, Waste management, Dealerships & Quick lubes - Pumps
* * * * Note: Model # 260101 is to be used for fluids with viscosities greater than 1000 centistokes. * * * *
